Right Angle Hydrant Landing Valve HL-2
Angle Landing ValvesNominal size: DN65Handwheel material: Ductile IronThe inlet on an instantaneous valve can be either flanged or screwed.Pressure rating: low pressure up to 15 barStrictly designed and constructed in accordance with BS5041 standardTh…
Product Details
- Angle Landing Valves
- Nominal size: DN65
- Handwheel material: Ductile Iron
- The inlet on an instantaneous valve can be either flanged or screwed.
- Pressure rating: low pressure up to 15 bar
- Strictly designed and constructed in accordance with BS5041 standard
- The valves are suitable for both on-shore and off-shore applications
- Flange drilling complying with BS4504 Part 2 :1974 /Table 16/21
- Dlievery hose connection complying with BS336:2010
- All the products will be tested before being packaged for shipment.
| Right-Angle Landing Valve Screwed End | A22 | 2.5" DN65 | Bronze LG2 |
