Pilot Rope Ladder PRL-1
Name:
Marine Escape Rope Ladder
Pilot Rope Ladder
Ship and vessel flexible line ladder
Wood Pilots Rope ladder
Pilot Embarkation Rope Ladder
Embarkation wooden rope ladder
Wooden Escape rope ladder
Marine lifesaving soft steps
Marine Safety Rope Ladder
Climbing Rope Ladder
Char.
Color: Wooden
Type: A & B
Weight:
Total Height:
Base Diameter:
Buoyancy to support Person:
Summary
1) SOLAS approved Rope Ladder
2) Vessel & Vessel Embarkation
3) Willow material
-Specification
1. Equipped in the embarking place of the life raft and boat, for pilots to board and leave the vessels.
2. In accordance with the 2000 Amendments to SOLAS 1974 and LSA.
3. The lowest 4 steps are rubber plates with steel lining; The count-down fifth plate is spreader step, and there are 8 short boards between two neighboring spreader steps; The distance between two neighboring steps :310 ± 5 mm.
Name |
Size (mm) |
Orifice |
Material |
|
Short Board |
Long Board |
|||
Pilot’s Rope Ladder |
525×115×28 (flat board) |
1800×115×28 |
Φ25mm |
willow |
525×115×(30~38) 525×115×(30~60) (slotting board) |
||||
Rope Ladder |
525×115×28 (flat board) |
1800×115×28 |
||
525×115×(30~38) 525×115×(30~60) (slotting b |
